c type vulcanizing press

(1)
C Type Vulcanizing Press
C Type Vulcanizing Press

C Type Vulcanizing Press

Product Summary: c type vulcanizing press

Key Features

1.Electrical Platens: The press is equipped with two electrical platens, one of which serves as the working layer.

2.Automatic Operation: PLC (Programmable Logic Controller) controlled, enabling automatic operation and improving production efficiency.

3.Height Adjustability: The height from the floor to the underside of the top heated platen can be customized according to client requirements.



Product Category: Jaw Vulcanizer Machine

Description

鄂式硫化机


The Main Technical Parameter

产品型号TypeXLE-Q5000×400×3XLB-D5486×508/8.5×2
公称合模力Total Pressure (Tons)1000 850×2
热板规格Plate Size(mm)5000×400×705486×508×80
热板间距Daylight (mm)150 400
工作层数Layers
柱塞行程Piston Stroke (mm)450 400
开/合模速度Open/Close Mould Speed (mm/s)≥15≥25/≥20
液压缸直径Cylinder Diameter(mm)φ285φ285
液压缸数量Cylinder NO. (Pcs)8×2
电机功率Motor Power (kw)11+5.515.0×2+11


Application
